With the MC – Silver IT 65 G all manufacturing handling is done with extreme care and maximum attention is paid to maintaining a very constant characteristic impedance along the whole cable, as well as in the microdomain, to prevent signal reflections even up to very high frequencies. MC – Silver IT 65 G exhibits an extremely extended frequency range of…
Description
With the MC – Silver IT 65 G all manufacturing handling is done with extreme care and maximum attention is paid to maintaining a very constant characteristic impedance along the whole cable, as well as in the microdomain, to prevent signal reflections even up to very high frequencies. MC – Silver IT 65 G exhibits an extremely extended frequency range of 65 GigaHertz. Precautions must be taken to prevent bending around a very small radius. The minimum safe value of the bending radius is 58 mm. The external diameter of the MC – Silver IT 65 G is: 5.8 mm.; a size that perfectly matches our 5.5 mm gold RCA connector. Analogue interconnect – unbalanced
Additional information
| Technical specifications | Type of cable: Analogue interconnect – unbalanced, Available versions: RCA, Jacket color: Purple, Product range: Mid-range, Conductor material: Silver plated OFC, Conductor diameter: 1.4 mm, Shielding: Double shielded, Cable diameter: 5.8 mm, Resistance: 0.0143 Ω/m (conductor), Capacitance: 81 pF/m |
|---|
